Luxman CL-38uC Valve Preamplifier
Luxman CL-38uC Valve Preamplifier
Regular price
£4,800.00 GBP
Regular price
Sale price
£4,800.00 GBP
Unit price
/
per
Tax included.
Couldn't load pickup availability
Gorgeous Japanese-made valve preamp that's beautifully engineered and finished, operating very quietly and sounding great. Good quality adjustable MM/MC phono stage. Very analogue, very nice!
Match with Luxman's own stereo power amp, or build a hybrid valve / solid state combo with a more powerful transistor power amp
Specification
| Input sensitivity/ input impedance |
PHONO (MM): 2.0mV/47kΩ PHONO (MC high): 0.3mV/100Ω PHONO (MC low): 0.08mV/30Ω LINE: 190mV/50kΩ BAL.LINE: 190mV/20kΩ *2 |
|---|---|
| Output/output impedance | Rated 1V/300Ω |
| Frequency response | PHONO: 20Hz to 20kHz (±0.5dB) LINE/BAL.LINE: 10Hz to 70kHz (within -3.0dB) |
| Total harmonic distortion | 0.006% or less (1kHz) 0.06% or less (20Hz to 20kHz) |
| S/N ratio (IHF-A) | PHONO (MM): 68dB or more PHONO (MC high): 63dB or more PHONO (MC low): 60dB or more LINE/BAL.LINE: 100dB or more |
| Tone control | ±8dB, selectable frequency range BASS: 150/300/600Hz, TREBLE: 1.5k/3k/6kHz |
|---|---|
| Low cut | 30Hz(-6dB/oct.) |
| Circuit | SRPP |
| Vacuum tubes | ECC83S×3, ECC82×5 |
| Power supply | 230V~(50Hz)/115V~(60Hz) |
| Power consumption | 35W |
| External dimensions | 440(W) x 169(H) x 307(D) mm 19mm front panel knob of and 12mm rear panel terminals are included in the depth measurement |
| Net weight | 13.3kg (main unit) |
| Accessories | Remote control (RA-19), Power cable |
| *2 This unit uses transformer equipped balanced inputs. Since the maximum input level at the balanced inputs is equivalent to 2.5 Volts, please be aware that the audio signal may be distorted if you connect a device with a higher output level (higher output voltage). There is no problem when using Luxman products (CD players etc.). For details, please refer to the instruction manual for the equipment to be used. |
DEMONSTRATION
It would be our pleasure to demonstrate this product in store for you
SHIPPING
Available for UK & EU shipping, please get in touch to arrange EU shipping
WARRANTY
All new products come with a manufactures warranty
REPAIRS, SALES & UPGRADES
Please contact us if you own gear that you’d like to sell, or that would benefit from service / repair or an upgrade
